Place of Origin: | China |
---|---|
Brand Name: | OUQI |
Certification: | ISO9001:2008 ISO14001:2004 |
Model Number: | Straight Coolant Rods |
Minimum Order Quantity: | 10pc |
Price: | negotiable |
Packaging Details: | plastic box/box + Cartons |
Delivery Time: | Standard products in one week |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 5000kgs per month |
Binder: | 14% | ISO Grade: | K05-K10 |
---|---|---|---|
Diameter: | 9mm | ID: | 1.0mm |
Length: | 330mm | Surface Roughness: | Raw Sintered Blank |
Circularity: | 0.15-0.3mm | Straightness: | 0.15-0.3mm |
Density: | 6.4 | Hardness HHV30: | 1580 |
T.R.S: | 2000 | KIC: | 8.5 |
High Light: | K05 Cermet Carbide Rods,Machining Steel Cermet Carbide Rods |
Cermet Tungsten Carbide Rods with One straight Holes K05-K10 for machining steel
ISO K05-K10
Cobalt: 14%
Outer diameter 9mm +0.3
Inner diameter: 1.0 +/-0.15
Length: 330mm +3mm
Surface roughness: Raw sintered Ra 6.3 or as required
Application: particularly for the finish machining of steel. Thanks to its high oxidation resistance and low tendency to stick it is particularly suitable for the production of uncoated reamers.
Grade datasheet:
|
For more grades details, please kindly check the general datasheet in the following details:
Regular size for one central hole carbide rods:
Outer Diameter mm | Inner Diameter mm | Length mm | |||
OD | Tol. | ID | Tol. | Length | Tol. |
2.50 | +0.2/+0.5 | 0.3 | ±0.1 | 330 | 0/+5.0 |
4.00 | +0.2/+0.6 | 1.0 | ±0.15 | 330 | 0/+5.0 |
5.00 | 1.0 | ±0.15 | 330 | 0/+5.0 | |
5.00 | 1.5 | ±0.15 | 330 | 0/+5.0 | |
6.00 | 1.0 | ±0.15 | 330 | 0/+5.0 | |
6.00 | 1.5 | ±0.15 | 330 | 0/+5.0 | |
8.00 | 1.0 | ±0.15 | 330 | 0/+5.0 | |
8.00 | 1.5 | ±0.15 | 330 | 0/+5.0 | |
9.00 | +0.3/+0.7 | 1.0 | ±0.15 | 330 | 0/+5.0 |
10.00 | 1.0 | ±0.15 | 330 | 0/+5.0 | |
10.00 | 2.0 | ±0.2 | 330 | 0/+5.0 | |
11.00 | 1.0 | ±0.15 | 330 | 0/+5.0 | |
12.00 | 1.0 | ±0.15 | 330 | 0/+5.0 | |
12.00 | 2.0 | ±0.2 | 330 | 0/+5.0 | |
14.00 | 2.0 | ±0.2 | 330 | 0/+5.0 | |
16.00 | +0.4/+0.8 | 2.0 | ±0.2 | 330 | 0/+5.0 |
16.00 | 3.0 | ±0.25 | 330 | 0/+5.0 | |
18.00 | 3.0 | ±0.25 | 330 | 0/+5.0 | |
20.00 | 3.0 | ±0.25 | 330 | 0/+5.0 | |
22.00 | 3 | ±0.25 | 330 | 0/+5.0 | |
24.00 | 4 | ±0.30 | 330 | 0/+5.0 | |
25.00 | 5 | ±0.35 | 330 | 0/+5.0 |
Outer Diameter mm | TK mm | Inner Diameter mm | Deviation of holes position≤(mm) a |
Length mm | ||||
OD | Tol. | TK | Tol. | ID | Tol. | Length | Tol. | |
4.30 | +0/+0.3 | 1.8 | -0.4/0 | 0.800 | ±0.1 | 0.15 | 330 | 0/+5.0 |
5.30 | 2.0 | -0.4/0 | 0.800 | ±0.1 | 0.20 | 330 | 0/+5.0 | |
6.30 | 3.0 | -0.5/0 | 1.000 | ±0.15 | 0.20 | 330 | 0/+5.0 | |
7.30 | 3.5 | -0.5/0 | 1.000 | ±0.15 | 0.20 | 330 | 0/+5.0 | |
8.30 | 4.0 | -0.6/0 | 1.000 | ±0.15 | 0.20 | 330 | 0/+5.0 | |
9.30 | 4.0 | -0.6/0 | 1.400 | ±0.15 | 0.20 | 330 | 0/+5.0 | |
10.30 | 5.0 | -0.6/0 | 1.400 | ±0.15 | 0.20 | 330 | 0/+5.0 | |
11.30 | +0/+0.4 | 5.0 | -0.6/0 | 1.400 | ±0.15 | 0.28 | 330 | 0/+5.0 |
12.30 | 6.0 | -0.6/0 | 1.750 | ±0.15 | 0.30 | 330 | 0/+5.0 | |
13.30 | 6.0 | -0.6/0 | 1.750 | ±0.15 | 0.34 | 330 | 0/+5.0 | |
14.30 | 7.0 | -0.6/0 | 1.750 | ±0.15 | 0.37 | 330 | 0/+5.0 | |
15.30 | 8.0 | -0.6/0 | 2.000 | ±0.2 | 0.37 | 330 | 0/+5.0 | |
16.30 | 8.0 | -0.6/0 | 2.000 | ±0.2 | 0.40 | 330 | 0/+5.0 | |
17.30 | +0/+0.6 | 9.0 | -0.6/0 | 2.000 | ±0.2 | 0.47 | 330 | 0/+5.0 |
18.30 | 9.0 | -0.6/0 | 2.000 | ±0.2 | 0.50 | 330 | 0/+5.0 | |
19.30 | 9.0 | -0.6/0 | 2.000 | ±0.2 | 0.50 | 330 | 0/+5.0 | |
20.30 | 10.0 | -0.8/0 | 2.500 | ±0.25 | 0.50 | 330 | 0/+5.0 |
General tolerance for the h6 finished ground solid carbide rods | ||||||||||
Diameter | Tolerance μm | Length | Tolerance | Straightness | Tolerance | Circularity | Tolerances | |||
<3.0 | -6/0 | <100.0 | +0.5/+1.0 | <4.0 | 0.07 | <3,0 | 2,0 micron | |||
3.0-6.0 | -8/0 | 100.0-165.0 | +1.0/+2.5 | 4.5-5.0 | 0.06 | 3,0- 6,0 | 2,5 micron | |||
6.0-1.0 | -9/0 | 165.0-335.0 | +1.0/+6.0 | 5.5-12 | 0.05 | 6,1-10,0 | 3,0 micron | |||
10.0-18.0 | -11/0 | >12.5 | 0.04 | 10,1-18,0 | 3,5 micron | |||||
18.0-30.0 | -13/0 | 18,1- 30,0 | 4,0 micron | |||||||
30.0-50.0 | -16/0 | 30,1- 50,0 | 5,0 micron |
